L59 Holy Grail´59 Relic

Description

The parts are sourced from Precision Guitar Kits. Made in Canada.

Body details

Total body thickness: 6.9 cm

Drilling for electronics

Solid carved top

Precision-cut neck pocket for precise joining

Mast details:

22 frets, 63.5 cm scale

Mast angle: 4.4 degrees

Long shank design cut for pills

Headstock angle: 11 degrees

Nut width: 3.8 cm

Fingerboard radius: 30.5 cm

Option specifications:

60's Slim: 1st fret 0.8″ / 12th fret 0.885″

59 Medium: 1st fret 0.877″ / 12th fret 0.976″

Big JR: 1st fret 0.955″ / 12th fret 1.125″

The wraparound bridge will have 11 mm (7/16″) diameter holes spaced 82 mm (3.23″) apart.

Nashville: TOM/Stop Tail will have 11 mm (7/16″) diameter holes spaced 74 mm (2.91″) apart. The tailpiece will have 11 mm (7/16″) diameter holes spaced 82 mm (3.23″) apart.

ABR1 The TOM/Stop Tail bridge will have 3 mm diameter holes and 74 mm spacing. The tailpiece will have 11 mm diameter holes and 82 mm spacing.

The paddle headstock measures 17 cm long and 8.5 cm wide.
